General Specifications
| Year | 1999 |
| Brand | Engel |
| Tonnage | 200 Ton (Thermoset Shuttle) |
| Shot Size | 32.5 oz. |
| Region |
|
| Model Number | ES1350H-200V |
| Type | horizontal |
| Options & Upgrades | Shuttle Table, BMC Suffer, Insulating Plates for Platens, BMC Hardened Barrel and Screw, Extended Water Cooled Nozzle, Core Pull on Movable Platen, Several additional options on file |
Technical Specifications
| Clamp |
|
| Platen Size | 75.70" inchesx 21.10" inches |
| Daylight Min | 5.91" inches |
| Daylight Max | 39.09" inches 20.98" Max Mold Height |
| Core Pull Sequences | Yes |
| Types of Controls | EC100 AO3 |
| Voltage | 460 |
| Dimensions | 12' ftx 11.4' ftx 13' ft |
Condition
| Overall Condition | Very Good |
| Barrel & Screw | Very Good |
| Material Run | Thermoset |
