2008 Netstal - 420 Ton

2008 Netstal

420 Ton 462 US ton 2-Color | 13.31 / 6.81 oz

General Specifications

Year2008
Brand Netstal
Tonnage420 Ton (462 US ton 2-Color)
Shot Size13.31 / 6.81 oz.
Region
  • USA
  • North America
Model NumberSynergy 4200K-900/460
Typehorizontal
Options & Upgrades2-Color machine, Core Pull, Injection Accumulators, 2 sets of moving platen guides to support stack mold center support, Set up to run Valve Gates or Hot Runner Tips, Can run Hydraulic electors on both or one platen
Machine Notes

2nd injection unit placed at a 35% angle behind the fixed platen

High Speed Machine

Two Machines Available!!

Technical Specifications

Clamp
  • Toggle
Tie Bar Distance28.07 inches  x  28.07 inches
Daylight Min33.46 inches
Daylight Max80,71 inches 53.15 Maximum Mold Height
Core Pull Sequences Yes
Types of ControlsDSP Controls
Voltage460
Dimensions 26.52 ftx 7.37 ftx 7.71 ft

Condition

Overall ConditionExcellent
Barrel & ScrewExcellent
Material RunPP, PS, HDPE
