1999 Van Dorn - 500 Ton

1999 Van Dorn

500 Ton | 59 oz

General Specifications

Year1999
Brand Van Dorn
Tonnage500 Ton
Shot Size59 oz.
Region
  • USA
  • North America
Model Number500 HP 2800
Typehorizontal
Options & UpgradesReinforced Platens
Machine Notes

Replaced and updated Various I/O boards ANA, SEQ - temperature board- rebuilt both advance cylinders- new fiber optic from op station to rack – CN valve/ 2 directional valves. EHST valve, replaced one pump cartridge, replaced various cartridge O-rings and new cartridge. All new oil filters, replaced various seals ,advance cylinders, ANA card. All new heater control relays on both. Added relay for color feeder.

Technical Specifications

Clamp
  • Hydraulic
Tie Bar Distance32.5 inches  x  32.5 inches
Platen Size 47 inchesx  47 inches
Daylight Min12/ 28 inches With and Without Ejector Box & Ram Spacers
Daylight Max52 / 68 inches With and Without Ejector Box & Ram Spacers
Types of ControlsPathfinder 5000
Voltage460
Dimensions 31.1 ftx 6.7 ftx 9.8 ft

Condition

Overall ConditionVery Good
Barrel & ScrewVery Good
