2008 Electric JSW - 1800 Ton

2008 JSW

1800 Ton | 167 oz

General Specifications

Year2008
Brand JSW
Tonnage1800 Ton
Shot Size167 oz.
Region
  • Mexico
  • North America
Model NumberJ1800 EL!!! 5200H
Typehorizontal
Options & UpgradesMachine includes Robot, Hopper and Dryer, Jet Loader, Sequential Timer for Valve Gate, 3 Hot Runner Controls
Machine Notes

5 Machines available

Machine includes Robot, Hopper and Dryer, Jet Loader, Sequential Timer for Valve Gate, 3 Hot Runner Controls, 6 Core Pulls on Stationary and Movable Platen

Technical Specifications

Clamp
  • Double Toggle Electric
Tie Bar Distance72.83" inches  x  63.78" inches
Platen Size 100.39" inchesx  91.34" inches
Daylight Min31.50" inches
Daylight Max125.98" inches 59.06 Max Mold Height
Core Pull Sequences Yes 6 Core Pulls on Stationary and Movable Platen
Types of ControlsSyscom 2000
Dimensions 49.02' ftx 12.10' ftx 11.52' ft

Condition

Overall ConditionExcellent
Barrel & ScrewExcellent
