Sold
General Specifications
| Year | 2020 |
| Brand | Sold Nissei |
| Tonnage | 2755 Ton (2500 metric tons) |
| Shot Size | 481 oz. |
| Region |
|
| Model Number | NUX2500-1100L |
| Type | horizontal |
| Machine Notes | The machine comes with a one year warranty, supervised set up of the machine and assembly, machine start up and training. |
Technical Specifications
| Clamp |
|
| Tie Bar Distance | 72.0 inches x 64.2 inches |
| Platen Size | 96.9 inches x 89.0 inches |
| Daylight Min | 31.5 inches |
| Daylight Max | 133.9 inches 63.0" Maximum Mold Thickness |
| Core Pull Sequences | Yes 4 Hydraulic Core Pull 2 On Each Platen |
| Types of Controls | TACT IV |
| Voltage | 460 |
| Dimensions | 46.26 ft x 15.39 ft x 12.19 ft |
Condition
| Overall Condition | New |
| Barrel & Screw | Like New |
| Hours | Zero Production hours |
| Material Run | None only set up and testing performed |
| Condition Notes | Machine is in like new condition |
