Sold
2012 Sold Engel
770 Ton | 168 oz
General Specifications
| Year | 2012 |
| Brand | Sold Engel |
| Tonnage | 770 Ton |
| Shot Size | 168 oz. |
| Region |
|
| Model Number | Pico 7050/770 US |
| Type | horizontal |
| Options & Upgrades | Includes Viper 40 Robot, Magnetic Platens |
| Machine Notes | Includes Viper 40 Robot, Magnetic Platens, Ecodrive - 40-60% Less Energy Consumption, B-Metallic Barrel & Barrier Screw, Ceramic Heater Bands, Pneumatic Shutoff Valve, Pneumatic Valve Gate on Each Platens, Speed Control Electric Screw Drive, High Base, 200mm Increased Mold Height, Electrically Adjustable Variable Displacement Pump With Pressure and Volume Regulation. Original Order Sheet Available with Further Details. |
Technical Specifications
| Clamp |
|
| Tie Bar Distance | 43.3 inches x 37.8 inches |
| Platen Size | 59.4 inches x 56.7 inches |
| Daylight Min | 17.7 inches |
| Daylight Max | 80.7 inches Max Mold Height 45.27 |
| Core Pull Sequences | Yes 1 on fixed Platen 2 on Movable Platen |
| Types of Controls | CC200 |
| Voltage | 460 |
Condition
| Overall Condition | Excellent |
| Barrel & Screw | Excellent |
| Material Run | PP, HDPE |
